Pipe Processing Technical Institute (Pipe Processing TI) specializes in rotary draw pipe bending—a high-precision process used to form tight-radius, repeatable bends in metal tubing and piping. This technique is widely used in industries where dimensional accuracy, aesthetics, and structural performance are critical, including automotive, aerospace, and architectural fabrication.
Our draw pipe bending services provide unmatched control over bend radius and wall integrity, making them ideal for both small-diameter tubing and heavy-duty structural applications.
What Is Draw Pipe Bending?
Rotary draw bending—also known as draw pipe bending—uses a die to clamp and rotate the pipe while a pressure die holds it in place, guiding it smoothly around a fixed radius. This process allows for tight-radius pipe bends with minimal ovality or wall thinning, even on thin-walled tubing.
Unlike compression or roll bending, rotary draw bending enables complex multi-plane bending, perfect for custom shapes or high-performance assemblies.
Draw Pipe Bending Capabilities and Specifications
Our roll bending service supports a wide range of pipe dimensions, materials, and project types:
- Pipe diameters: ¼” to 5″
- Bend radii: Tight-radius and standard-radius capabilities
- Wall thickness: Thin-wall to heavy gauge
- Bend angles: Up to 180°, including compound bends
- Materials supported:
– Stainless steel
– Carbon steel
– Aluminum
– Copper, brass, and titanium - Profiles: Round, square, rectangular tubing
- Tolerances: High precision (±0.5° angle; ±1/32″ position)
With our CNC rotary draw bending machines, we produce clean, repeatable bends with tight control over geometry and finish.
How Pipe Wall Thickness Changes
Stress Diagram in Pipe Bending
You need to take several factors into consideration for pipe bending such as bending radius, materials (esp, SUS, high-tensile steel plates, etc.), and more.
| Pipe Bending Methods | How Pipe Wall Thickness Changes |
|---|---|
| Press Bending | Conventional (no bending technique used) |
| Roll Bending | Conventional (no bending technique used) |
| Compression Bending | Press Bending |
| Draw Bending | Stretch Bending |
| Stretch Bending | Stretch Bending |
Compression Bending
What happens to wall thickness in press bending
A pipe is bent while being pressed. This method works well for materials that are hard to expand, as the outside tensile force is small. It’s also suitable for thin-wall or small-radius bending. However, wrinkles may occur due to compression on the inside, making adjustment difficult.
Draw Bending & Stretch Bending
What happens to wall thickness in stretch bending
A pipe is bent while getting stretched. Wrinkles and springback hardly occur as the inside material of the pipe has less buckling. On the other hand, materials that are hard to expand may fracture as the tensile force outside of the material gets bigger.
Advantages of Our Pipe Bending Services
Choosing Pipe Processing TI for your pipe bending needs means working with a trusted team that delivers:
Wide Range of Pipe Diameters
A broad pipe diameter ranges covered (φ10-φ30 for Hydraulic Piping / φ30-φ100 for Exhaust Piping).
Prototyping to Mass Production
Multi-product, small-lot production system. Manufacturing lead times as short as 1 week or JIT.
Quick Manufacturing Lead Time
For mandrels: 2-day manufacturing lead time. Non-contact 3D measuring instruments for thorough inspection.
Wrinkle-Free Results
Accurate bends without kinks or flattening, even on thin walls. Multi-product, small-lot production system for cost reduction.
Trusted Pipe Bending Supplier
Proudly delivering high-quality, custom pipe bending solutions backed by over 60 years of industry experience and trusted expertise.
Tailored Bending Solutions
Custom bends for architectural, structural, and industrial needs. Precision-made to match your exact specs and standards.
We combine technology with craftsmanship to ensure every bend meets the exact specifications your project demands.
